in Stock 10 20 40 60 80 100 150 200 Mesh Duplex Stainless Steel Wire Mesh

in Stock 10 20 40 60 80 100 150 200 Mesh Duplex Stainless Steel Wire Mesh

CHEMICAL COMPOSITION PHYSICAL PROPERTIES Specification List

Send your inquiry

DESCRIPTION

Basic Info.
Usage Liquid Filter
Type Woven Wire Mesh
Hole Shape Square
Structure Single Network
Application Filtration
Technique Woven
Weave Style Plain Weave, Twill Weave
Certification ISO9001: 2015
Transport Package Rolls in Plastic Film, Then in Wooden Case
Specification 1mx30m in roll
Trademark HIGHTOP
Origin Hebei, China
HS Code 73141400
Production Capacity 20000 Square Meters/Month
Product Description

in Stock 10 20 40 60 80 100 150 200 Mesh Duplex Stainless Steel Wire Mesh

Name Duplex stainless steel wire mesh
Material UNS S31803
mesh count 1-180
Wire diameter 0.05mm-2.0mm
Weave style Plain and Twill Weave
Feature duplex stainless steel has excellent corrosion-resistant ability. Compared with austenitic,lower thermal expansion coefficient, high thermal conductivity, is widely used in chemical, seawater desalination equipment.
Application 1. For acid, alkali screening and filtration under industrial conditions2. For the oil industry to do mud net, chemical fiber chemical industry, so sieve filter, electroplating3. For mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries4. keeping different species of inserts out, filtering some small items, mending windows and doors, etc


in Stock 10 20 40 60 80 100 150 200 Mesh Duplex Stainless Steel Wire Mesh

CHEMICAL COMPOSITION

Material C≤ Mn≤ Si≤ S≤ P≤ Cr≤ Ni Mo N
S31803 0.03 2 1 0.02 0.03 21.0/23.0 4.50/6.50 2.50/3.50 0.08/0.20
00Cr22Ni5Mo3N

PHYSICAL PROPERTIES

Material σb(Mpa)≥ σs(Mpa)≥ δ(%)≥ Hardness (stiffness)
(HB) (HRC)
S31803 620 450 25 290 30.5
00Cr22Ni5Mo3N


Specification List

Mesh Inch S.W.G Aperture (mm) Wire Diameter (mm) Weight (Kg/m2) Effective (%)
3mesh 14 6.27 2.2 62 7
4mesh 20 5.45 0.914 76 2.1
5mesh 22 4.36 0.711 76 1.3
6mesh 18 3.04 1.22 50 4.3
8mesh 24 2.5 0.559 67 1.5
10mesh 20 1.63 0.91 41 4
12mesh 26 1.74 0.457 68 1.4
14mesh 26 1.36 0.46 57 1.4
16mesh 28 1.21 0.376 55 1.2
18mesh 30 1.1 0.315 60 0.85
20mesh 30 0.95 0.315 58 0.95
22mesh 32 0.88 0.274 57 0.8
24mesh 32 0.78 0.274 55 0.85
26mesh 32 0.74 0.274 51 0.7
32mesh 34 0.56 0.234 50 0.84
36mesh 34 0.47 0.234 45 0.95
38mesh 36 0.48 0.193 46 0.7
40mesh 36 0.44 0.193 50 0.8
80mesh 40 0.198 0.12 44 0.58
100mesh 42 0.154 0.1 37 0.5
120mesh 44 0.13 0.081 40 0.39
150mesh 46.5 0.115 0.055 48 0.206
180mesh 47 0.09 0.051 410 0.24
